The Platinous series lets you select from a variety of sizes, ranges, and options to meet your specific environmental testing requirements. ESPEC Platinous series includes features for quality and reliable operation:

  • Stainless steel exterior
  • Energy-efficient refrigeration with an exclusive electronic expansion valve system
  • Specialized humidity generation and control
  • Unique thermal break construction for extreme testing
  • Casters, cable port, shelf, & USB port standard
  • ETL-listed electrical panel conforming to UL 508A

ESPEC can add safety options for testing lithium-ion batteries or other products. See the options tab for a list or the Battery brochure below

A new streamlined controller

ESPEC makes operating an environmental test chamber easier than ever with the new P-300 controller. An updated ‘tabbed’ user interface allows faster access to any screen. Standard USB and optional Ethernet interfaces make programming and data acquisition much simpler. In addition, improved algorithms make control faster and smoother.

Improved programming and data collection via computer

  • Standard USB port for uploading and downloading test programs and operation datalogs.
  • Optional remote monitoring, programming, and data collection via our Ethernet/LAN-based Web Controller
  • Direct access via an optional RS-232 serial port or GP-IB/LabView.

Energy-saving operation

Built into the P-300 controller are improved control algorithms for more efficient chamber operation. Invisible to the end user, the P-300 uses advanced control of an electronic expansion valve to save energy and improve control of the refrigeration system. Additional improvements in refrigeration and heater operation make the new generation of ESPEC Platinous chambers the most energy efficient ever.

Features for Platinous Chambers

Well Thought-out Cabinet Design

  • Stainless steel interior with rounded corners - superior to square, welded corners
  • Stainless steel exterior construction for durability over time
  • Optional viewing window with full-pane heaters to help keep condensation and frost clear. Provides great visibility into the chamber.
  • Chamber light built into the window for easy viewing without glare
  • One 4" diameter cable port, centered in the left wall (additional ports optional)
  • One stainless steel shelf with adjustable support rails (not clips)
  • Heavy-duty casters with adjustable leveling feet
  • Hinged service panels for easy access

Helpful Operational Features

  • Independent "Product Temp. Protector" with user-set limits, part of a three-tier safety system
  • Electrical disconnect switch is included, with lock-out/tag-out




Get A Fast, Free Price Quote

Photo of Platinous
Updated with a new controller and improved operation

Product Suggestions
Reach-in Test Chambers
Model Number Interior Dimensions
(W x D x H)
Interior Volume Temperature Range Humidity Control Change Rate
(heat/cool)
Notes
EPU-2H 19.7" x 23.6" x 29.5" 8 cu. ft. -35 to 180°C No up to 5.5°C/min.
EPU-3H 23.6" x 31.5" x 33.5" 14 cu. ft. -35 to 180°C No up to 3.25°C/min.
EPU-4H 39.4" x 35.5" x 39.4" 32 cu. ft. -35 to 180°C No up to 5°C/min.
EPL-2H 19.7" x 23.6" x 29.5" 8 cu. ft. -35 to 180°C Yes up to 5.5°C/min.
EPL-3H 23.6" x 31.5" x 33.5" 14 cu. ft. -35 to 180°C Yes up to 3.25°C/min. Quick Ship
EPL-4H 39.4" x 35.5" x 39.4" 32 cu. ft. -35 to 180°C Yes up to 5°C/min. Quick Ship
EPZ-2H 19.7" x 23.6" x 29.5" 8 cu. ft. -70 to 180°C No up to 6°C/min.
EPZ-3H 23.6" x 31.5" x 33.5" 14 cu. ft. -70 to 180°C No up to 5°C/min.
EPZ-4H 39.4" x 35.5" x 39.4" 32 cu. ft. -70 to 180°C No up to 6°C/min.
EPX-2H 19.7" x 23.6" x 29.5" 8 cu. ft. -70 to 180°C Yes up to 6°C/min.
EPX-3H 23.6" x 31.5" x 33.5" 14 cu. ft. -70 to 180°C Yes up to 5°C/min. Quick Ship
EPX-4H 39.4" x 35.5" x 39.4" 32 cu. ft. -70 to 180°C Yes up to 6°C/min. Quick Ship

      Click model number for details, including metric & english units.

Get improved performance, energy savings, plus USB access

New P-300 controller with USB

The exclusive ESPEC P-300 controller has USB and Ethernet features to make programming and data collection easier than before. The user interface uses tabs for faster access to any screen. Standard USB and optional Web Controller/Ethernet interfaces make programming and data acquisition much simpler. In addition, improved algorithms make operation faster and smoother.

DEMO: See how easy the P-300 is

USB port for upload/download of test profiles and test data

  • Test programs can uploaded or downloaded from the P-300 via USB thumb drive.
  • Create, edit, and store programs on a PC using the included Pattern Manager Lite software.
  • Accurate, repeatable testing by uploading the same program to multiple chambers.
  • Create your own back-up archive of programs, and get additional profiles from ESPEC's library.
  • Retrieve and download test operation data via USB thumb drive. Data timeframe is selectable.
  • For integrity, viewing test data on a PC and exporting to Excel requires included Pattern Manager Lite software.

Energy-saving operation

Invisible to the end user, the P-300 uses advanced cooling control via an electronic expansion valve, saving energy and improving temperature stability. Sophisticated future-looking algorithms make temperature ramping faster and smoother. These high-end features are unique to ESPEC. Additional improvements in refrigeration and heater operation will make the next generation of ESPEC chambers the most energy efficient ever.

Additional capabilities

  • Store up to forty programs, as well as three different constant-mode set-ups.
  • Multilingual display in English, Japanese, Chinese, or Korean.
  • Alarm diagnostics and history, plus a ‘back trace’ feature for troubleshooting.
  • Three programmable timers allow the user to set reminders for maintenance or other actions.
  • Energy saving by using only one compressor when testing above -10°C (for cascade refrigeration models).
  • Optional Ethernet/browser-based Web Controller access can also be used to upload and download programs, as well as data.
  • Optional Product Temperature Control allows faster ramping to the desired conditions on the sample.
  • Computer interface options for specialized programs: RS-232/serial or GP-IB.

P-300 Specification

Specification Features
Display

Color touch-screen, 6.5 inch diagonal, 640x480 resolution
Multilingual display in English, Japanese, Chinese, or Korean

Control Method

PID (Proportional, Integral, Derivative)
plus WRTC (Window Reference Trajectory Control)

Communications

Standard: USB External Memory port
Optional: RS-232, RS-485, GP-IB, Ethernet

Operating Modes
(as indicated in upper left of the display)

STOP: chamber off, programmer on
PGM: RUN runs selected test profile
CONSTANT: runs at set value continually

Program Capacity

40 programs, 99 steps per program

Programming Capabilities

Create or copy programs
Upload and download of programs via USB
Copy, edit, insert, and delete steps
Two nested loops to repeat steps 999 times
Selectable end-of-test modes
Create pause steps within programs
Soak control delays timer until setpoint is reached

Additional Functions

Alarm report lists last 1000 alarms and time occurred
Time signal relay control (with naming capability)
High/low limit alarm functions
Audible alarm with on-screen explanation
Selectable restart modes after power failure
Automatic start and stop functions
Keylock protection and configuration lock-out
Service guide and help screens
Three settable reminder alarms for PM
Running time meter is integral
RoHS directive lead-free compliant

Pattern Manager Lite Software

Allows creation, editing, and archive storage of test profiles on a PC
Test profiles may be uploaded and downloaded to P-300
Allows viewing and graphing of chamber operation data downloaded via USB
Operation data may be exported to CSV for use with Excel or other programs

Software Options

Learn more about ways to access ESPEC controllers via software our support page:
Software for P-300

Recommended: Web Controller

The ESPEC Web Controller is an embedded server/software solution for monitoring and programming your chamber via Ethernet. Works with P-300, SCP-220, F4T, & F4 controllers.

See the brochure
Self-install kit for existing units
Try the live demo now!

Independent of the controller itself, the Web Controller adds additional capabilities for datalogging, programming, alarm emails, and RESTful API.
